Fluid Square Galvanized Steel Pipe 27mm Hot Rolled For Construction
| Place of Origin | China |
|---|---|
| Brand Name | Tisco |
| Certification | ISO/ TUV/ SGS /BV and so on |
| Model Number | Galvanized Steel Tube |
| Minimum Order Quantity | 1/ Ton |
| Price | Negotiated |
| Packaging Details | Exporting package/wooden box package/Or per customers’ requirement |
| Delivery Time | 5-8 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 10000 Ton/Tons per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Galvanized Steel Tube | Tolerance | ±1% |
|---|---|---|---|
| Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, OIL PIPE, Chemical Fertilizer Pipe, Structure Pipe, Other | Special Pipe | API Pipe, Other, EMT Pipe, Thick Wall Pipe |
| Type | Galvanized Rectangular Steel Pipe | Shape | Round/Square /Rectangular |
| Outer Dia(mm) | 21.3-165mm/10*10-600*600mm/10*20-800*400mm | Wall Thickness(mm) | 0.5-2.5to1.5-5.5/0.4-27mm/0.4-27mm |
| Length | 5800 O R6000/6M Or Customized | End Finish | Plain/ Beveled Ends Or Threaded With Sockets/coupling And Plastic Caps. |
| Sample | Available | Zinc Coating | 30-275g/m2 |
| Price Term | FOB,EXW,CFR,CIF | Technique | ERW, Cold Rolled Hot Rolled Hot Dipped |
| High Light | Fluid Square Galvanized Steel Pipe,27mm Square Galvanized Steel Pipe,Construction Hot Rolled Galvanized Steel Pipe |
||
Product Description
Galvanized Steel Square Tube For Construction
Galvanized steel tube is a type of steel tubing that has been coated with a layer of zinc to prevent rust and corrosion. The process of galvanizing involves immersing the steel tube in a molten zinc bath, which results in a durable and protective coating that helps the tube resist the elements and other forms of damage. Galvanized steel tubes are commonly used in a wide range of applications, including construction, plumbing, automotive, and industrial settings. They are available in various shapes and sizes, such as round, square, and rectangular, to suit different requirements.
| Product name | Hot sale Prime Quality Galvanized Pipe |
| Material | Q235,SS400,A36 |
| Shape | Round/Square /Rectangular |
| Outer Dia(mm) | 21.3-165mm/10*10-600*600mm/10*20-800*400mm |
| Wall Thickness(mm) | 0.5-2.5to1.5-5.5/0.4-27mm/0.4-27mm |
| Length | 5800 o r6000/6M or customized |
| Surface Treatment | 1)Black,Pre-galvanized |
| 2)oiled,powder coating | |
| 3)Galvanized as your requirement | |
| PS:Pre galvanized steel pipe: 60-150g/m2; | |
| Hot dipped galvanized steel pipe: 200-400g/m2,350-400g/square meter | |
| End Finish | Plain/ beveled ends or threaded with sockets/coupling and plastic caps. |
| Packaging | Packing in bundle with steel strips; with seaworthy package at the end; could be done with your requirement. |
| Inspection | With Chemical Composition and Mechanical Properties Testing; Hydrostatic Test, Dimensional and Visual Inspection, With Nondestructive Inspection |
| Application | construction pipe, machine structure pipe, agriculture equipment pipe, water and gas pipe, Greenhouse pipe, Building material, Furniture tube, Low pressure fluid tube, etc |
| Others | 1:Special design available according to requirement |
| 2:Pipe can be necked dowm, punching hole on pipe wall. | |
| 3:Pipe fittings, elbows are available. | |
| 4.All production process are under the ISO9001:2000 strictly |
| Norminal Size(inch) | Outside Diameter | Wall Thickness (mm) |
Norminal Size(inch) | Outside Diameter(mm) | Wall Thickness(mm) | Norminal Size(inch) | Outside Diameter | Wall Thickness (mm) |
| 1/2” | mm | 0.8-3.0 | 2” | 60.3 | 1.0-4.5 | 6” | 168.3 | 1.5-10 |
| 3/4” | 21.3 | 0.8-3.0 | 2 1/2” | 73 or 76 | 1.0-4.5 | 8” | 219 | 1.5-10 |
| 1” | 26.7 | 0.8-4.0 | 3” | 88.9 | 1.0-4.5 | 10” | 273 | 1.5-15 |
| 1 1/4” | 42.2 | 0.8-4.0 | 4” | 114.3 | 1.0-6.0 | 12” | 323.8 | 1.5-15 |
| 1 1/2” | 48.3 | 0.8-4.5 | 5” | 141.3 | 1.0-6.0 | ... | ... | ... |
| Grade | Chemical Composition | Mechanical Properties | ||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
|
STEEL GRADE |
CHEMICAL COMPOSITION % | MECHANIC PROPERTY | C.B OF COATING | ||||||
| C | Si | Mn | S | p | T.S | Y.S | E.L | ||
| x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=180 | |
|
JIS G3302 SGCC |
12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK |
|
JIS G3302 SGCH |
12 | 10 | 21 | 18 | 6 | 680 | 650 | 20 | OK |
|
ASTM 653 CS.B |
29 | 30 | 60 | 35 | 30 | 386 | 250-380 | 20 | OK |
| DX51D+Z | 20 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK |
| G550 | 12 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK |
Delivery
FAQ
Q: What kind of work does your company do?
A: Our company is a professional manufacturer.
We mainly produces steel plate/pipe/coil/round bars
Q: What are the advantages of your company?
A:
(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance based on BL copy or LC at sight.
If you have another question, please contact us as below
Q: What about your price?
A: Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.
Q: How long is your delivery time?
A: Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality
assurance.Usually the delivery time is within5 days after we received your deposit.
