Cold Rolled Pre Galvanized Steel Pipe 165mm A36 Threaded For Handrails And Balustrades
| Place of Origin | China |
|---|---|
| Brand Name | Tisco |
| Certification | ISO/ TUV/ SGS /BV and so on |
| Model Number | Galvanized Steel Tube |
| Minimum Order Quantity | 1/ Ton |
| Price | Negotiated |
| Packaging Details | Exporting package/wooden box package/Or per customers’ requirement |
| Delivery Time | 5-8 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 10000 Ton/Tons per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Galvanized Steel Tube | Surface Treatment | Galvanized Coated |
|---|---|---|---|
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching | Tolerance | ±1% |
| Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, OIL PIPE, Chemical Fertilizer Pipe, Structure Pipe, Other | Shape | Round/Square /Rectangular |
| Outer Dia(mm) | 21.3-165mm/10*10-600*600mm/10*20-800*400mm | Wall Thickness(mm) | 0.5-2.5to1.5-5.5/0.4-27mm/0.4-27mm |
| Length | 5800 O R6000/6M Or Customized | End Finish | Plain/ Beveled Ends Or Threaded With Sockets/coupling And Plastic Caps. |
| Sample | Available | Zinc Coating | 30-275g/m2 |
| Price Term | FOB,EXW,CFR,CIF | Technique | ERW, Cold Rolled Hot Rolled Hot Dipped |
| High Light | Cold Rolled Pre Galvanized Steel Pipe,165mm Pre Galvanized Steel Pipe,A36 Threaded Galvanized Steel Pipe |
||
Product Description
Galvanized Steel Tube For Handrails And Balustrades
Advantages
Corrosion Resistance: Galvanized steel tube is coated with a layer of zinc, which provides a barrier against corrosion and rust. This makes it ideal for use in harsh environments where corrosion and rust are a concern.
Durability: The zinc coating on galvanized steel tube makes it highly durable and able to withstand the elements and other forms of damage.
Strength: Galvanized steel tube is stronger than many other types of steel tubing, making it suitable for applications that require high-strength materials.
Cost-effective: Galvanized steel tube is a cost-effective solution for many applications, as it is less expensive than other types of corrosion-resistant materials.
Easy to Work With: Galvanized steel tube is easy to cut, weld, and shape, making it ideal for use in a wide range of fabrication projects.
Low Maintenance: Galvanized steel tube requires minimal maintenance, as the zinc coating provides long-lasting protection against corrosion and rust.
Recyclable: Galvanized steel tube is fully recyclable, making it an environmentally friendly option for many applications.
| Product name | Hot sale Prime Quality Galvanized Pipe |
| Material | Q235,SS400,A36 |
| Shape | Round/Square /Rectangular |
| Outer Dia(mm) | 21.3-165mm/10*10-600*600mm/10*20-800*400mm |
| Wall Thickness(mm) | 0.5-2.5to1.5-5.5/0.4-27mm/0.4-27mm |
| Length | 5800 o r6000/6M or customized |
| Surface Treatment | 1)Black,Pre-galvanized |
| 2)oiled,powder coating | |
| 3)Galvanized as your requirement | |
| PS:Pre galvanized steel pipe: 60-150g/m2; | |
| Hot dipped galvanized steel pipe: 200-400g/m2,350-400g/square meter | |
| End Finish | Plain/ beveled ends or threaded with sockets/coupling and plastic caps. |
| Packaging | Packing in bundle with steel strips; with seaworthy package at the end; could be done with your requirement. |
| Inspection | With Chemical Composition and Mechanical Properties Testing; Hydrostatic Test, Dimensional and Visual Inspection, With Nondestructive Inspection |
| Application | construction pipe, machine structure pipe, agriculture equipment pipe, water and gas pipe, Greenhouse pipe, Building material, Furniture tube, Low pressure fluid tube, etc |
| Others | 1:Special design available according to requirement |
| 2:Pipe can be necked dowm, punching hole on pipe wall. | |
| 3:Pipe fittings, elbows are available. | |
| 4.All production process are under the ISO9001:2000 strictly |
| Norminal Size(inch) | Outside Diameter | Wall Thickness (mm) |
Norminal Size(inch) | Outside Diameter(mm) | Wall Thickness(mm) | Norminal Size(inch) | Outside Diameter | Wall Thickness (mm) |
| 1/2” | mm | 0.8-3.0 | 2” | 60.3 | 1.0-4.5 | 6” | 168.3 | 1.5-10 |
| 3/4” | 21.3 | 0.8-3.0 | 2 1/2” | 73 or 76 | 1.0-4.5 | 8” | 219 | 1.5-10 |
| 1” | 26.7 | 0.8-4.0 | 3” | 88.9 | 1.0-4.5 | 10” | 273 | 1.5-15 |
| 1 1/4” | 42.2 | 0.8-4.0 | 4” | 114.3 | 1.0-6.0 | 12” | 323.8 | 1.5-15 |
| 1 1/2” | 48.3 | 0.8-4.5 | 5” | 141.3 | 1.0-6.0 | ... | ... | ... |
| Grade | Chemical Composition | Mechanical Properties | ||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
|
STEEL GRADE |
CHEMICAL COMPOSITION % | MECHANIC PROPERTY | C.B OF COATING | ||||||
| C | Si | Mn | S | p | T.S | Y.S | E.L | ||
| x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=180 | |
|
JIS G3302 SGCC |
12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK |
|
JIS G3302 SGCH |
12 | 10 | 21 | 18 | 6 | 680 | 650 | 20 | OK |
|
ASTM 653 CS.B |
29 | 30 | 60 | 35 | 30 | 386 | 250-380 | 20 | OK |
| DX51D+Z | 20 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK |
| G550 | 12 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK |
Delivery
FAQ
Q: What kind of work does your company do?
A: Our company is a professional manufacturer.
We mainly produces steel plate/pipe/coil/round bars
Q: What are the advantages of your company?
A:
(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance based on BL copy or LC at sight.
If you have another question, please contact us as below
Q: What about your price?
A: Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.
Q: How long is your delivery time?
A: Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality
assurance.Usually the delivery time is within5 days after we received your deposit.
