Round 50mm Galvanized Steel Pipe Thick Wall Large For Oil And Gas Pipelines

Place of Origin China
Brand Name Tisco
Certification ISO/ TUV/ SGS /BV and so on
Model Number Galvanized Steel Tube
Minimum Order Quantity 1/ Ton
Price Negotiated
Packaging Details Exporting package/wooden box package/Or per customers’ requirement
Delivery Time 5-8 work days
Payment Terms L/C, T/T
Supply Ability 10000 Ton/Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Galvanized Steel Tube Special Pipe API Pipe, Other, EMT Pipe, Thick Wall Pipe
Type Galvanized Rectangular Steel Pipe Shape Round/Square /Rectangular
Outer Dia(mm) 21.3-165mm/10*10-600*600mm/10*20-800*400mm Wall Thickness(mm) 0.5-2.5to1.5-5.5/0.4-27mm/0.4-27mm
Length 5800 O R6000/6M Or Customized End Finish Plain/ Beveled Ends Or Threaded With Sockets/coupling And Plastic Caps.
Sample Available Zinc Coating 30-275g/m2
Price Term FOB,EXW,CFR,CIF Technique ERW, Cold Rolled Hot Rolled Hot Dipped
High Light

Oil 50mm Galvanized Steel Pipe

,

Gas 50mm Galvanized Steel Pipe

,

Thick Wall Large Galvanized Pipe

Leave a Message
Product Description

Galvanized Steel Tube For Oil And Gas Pipelines





Galvanized steel tubes are easy to clean and maintain, making them ideal for use in applications that require a high level of hygiene.
The uniform zinc coating on galvanized steel tubes provides a smooth surface that is ideal for painting and powder coating.
Galvanized steel tubes are resistant to abrasion and wear, making them suitable for use in applications involving heavy use or frequent handling.
The high strength-to-weight ratio of galvanized steel tubes makes them ideal for use in applications where weight is a concern.
Galvanized steel tubes are highly versatile and can be used in a wide range of applications across various industries.
They are available in different grades and thicknesses to suit different requirements and applications.



Product name Hot sale Prime Quality Galvanized Pipe
Material Q235,SS400,A36
Shape Round/Square /Rectangular
Outer Dia(mm) 21.3-165mm/10*10-600*600mm/10*20-800*400mm
Wall Thickness(mm) 0.5-2.5to1.5-5.5/0.4-27mm/0.4-27mm
Length 5800 o r6000/6M or customized
Surface Treatment 1)Black,Pre-galvanized
2)oiled,powder coating
3)Galvanized as your requirement
PS:Pre galvanized steel pipe: 60-150g/m2;
Hot dipped galvanized steel pipe: 200-400g/m2,350-400g/square meter
End Finish Plain/ beveled ends or threaded with sockets/coupling and plastic caps.
Packaging Packing in bundle with steel strips; with seaworthy package at the end; could be done with your requirement.
Inspection With Chemical Composition and Mechanical Properties Testing; Hydrostatic Test, Dimensional and Visual Inspection, With Nondestructive Inspection
Application construction pipe, machine structure pipe, agriculture equipment pipe, water and gas pipe, Greenhouse pipe, Building material, Furniture tube, Low pressure fluid tube, etc
Others 1:Special design available according to requirement
2:Pipe can be necked dowm, punching hole on pipe wall.
3:Pipe fittings, elbows are available.
4.All production process are under the ISO9001:2000 strictly



Norminal Size(inch) Outside Diameter Wall Thickness
(mm)
Norminal Size(inch) Outside Diameter(mm) Wall Thickness(mm) Norminal Size(inch) Outside Diameter Wall Thickness
(mm)
1/2” mm 0.8-3.0 2” 60.3 1.0-4.5 6” 168.3 1.5-10
3/4” 21.3 0.8-3.0 2 1/2” 73 or 76 1.0-4.5 8” 219 1.5-10
1” 26.7 0.8-4.0 3” 88.9 1.0-4.5 10” 273 1.5-15
1 1/4” 42.2 0.8-4.0 4” 114.3 1.0-6.0 12” 323.8 1.5-15
1 1/2” 48.3 0.8-4.5 5” 141.3 1.0-6.0 ... ... ...



Grade Chemical Composition Mechanical Properties
C Mn Si S P Yield Tensile Elongati
Strength Mpa Strenth Mpa -on %
Q195 0.06-0.12 0.25-0.50 ≤0.30 ≤0.045 ≤0.05 ≥195 315-430 ≥33
Q215 0.09-0.15 0.25-0.55 ≤0.30 ≤0.05 ≤0.045 ≥215 335-450 ≥27
Q235 0.12-0.20 0.30-0.67 ≤0.30 ≤0.045 ≤0.04 ≥235 375-500 ≥26
Q345 ≤0.20 1.00-1.60 ≤0.55 ≤0.04 ≤0.04 ≥345 470-630 ≥22



STEEL GRADE

CHEMICAL COMPOSITION % MECHANIC PROPERTY C.B OF COATING
C Si Mn S p T.S Y.S E.L
  x103 x103 x102 x103 x103 Mpa Mpa % d=180

JIS G3302 SGCC

12 30 41 31 21 480 300 13 OK

JIS G3302 SGCH

12 10 21 18 6 680 650 20 OK

ASTM 653 CS.B

29 30 60 35 30 386 250-380 20 OK
DX51D+Z 20 21 18 1.8 11 355 245 38 OK
G550 12 6 73 5 17 715 654 8 OK



Round 50mm Galvanized Steel Pipe Thick Wall Large For Oil And Gas Pipelines 0Round 50mm Galvanized Steel Pipe Thick Wall Large For Oil And Gas Pipelines 1Round 50mm Galvanized Steel Pipe Thick Wall Large For Oil And Gas Pipelines 2



Delivery



Round 50mm Galvanized Steel Pipe Thick Wall Large For Oil And Gas Pipelines 3



FAQ



Q: What kind of work does your company do?
A: Our company is a professional manufacturer.
We mainly produces steel plate/pipe/coil/round bars


Q: What are the advantages of your company?
A:
(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance based on BL copy or LC at sight.
If you have another question, please contact us as below

Q: What about your price?
A: Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.

Q: How long is your delivery time?
A: Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality
assurance.Usually the delivery time is within5 days after we received your deposit.
