2205 Duplex Stainless Steel Pipe Tubing High Strength For Oil And Gas Applications
Basic Properties
Place of Origin:
MADE IN CHAINA
Brand Name:
Baosteel，TISCO
Certification:
EN 10204 Type 3.1 / 3.2 available
Model Number:
201 / 202 / 301 / 302 / 303 / 304 / 304L / 305 / 309S / 310S / 316 / 316L / 317 / 317L / 321 / 347 / 409L / 410 / 420 / 430 / 440C / 2205 / 2507
Trading Properties
Minimum Order Quantity:
100kg
Price:
Negotiable (Request a Quote)
Payment Terms:
T/T，D/P，D/A，Western Union，PayPal
Supply Ability:
10000tons
Product Summary
2205 duplex stainless steel pipe is a nitrogen-enhanced duplex grade with a two-phase microstructure consisting of approximately 50% austenite and 50% ferrite. This balanced structure provides approximately twice the yield strength of standard austenitic stainless steels such as 304 and 316, ...
Product Details
Highlight:
Duplex Stainless Steel Pipe High Strength
,Duplex Stainless Steel Pipe Tubing
,2205 Duplex Pipe High Strength
Country Of Origin:
MADE IN CHAINA
Brand:
Baosteel，TISCO
Certifications:
ISO/EN 10204 Type 3.1 / 3.2 Available
Grade:
201 / 202 / 301 / 302 / 303 / 304 / 304L / 305 / 309S / 310S / 316 / 316L / 317 / 317L / 321 / 347 / 409L / 410 / 420 / 430 / 440C / 2205 / 2507 / 630 (17-4PH)
MOQ:
100kg
Price:
Negotiable (Request A Quote)
Packaging:
Wooden Case / Wooden Pallet / Steel Frame / Carton / Woven Bag
Delivery Time:
15-25days
Payment Terms:
T/T，D/P，D/A，Western Union，PayPal
Supply Capacity:
10000tons
Product Description
2205 duplex stainless steel pipe is a nitrogen-enhanced duplex grade with a two-phase microstructure consisting of approximately 50% austenite and 50% ferrite. This balanced structure provides approximately twice the yield strength of standard austenitic stainless steels such as 304 and 316, combined with excellent corrosion resistance.
2205 is the most widely used duplex stainless steel grade, offering an exceptional combination of high strength, good weldability, and superior resistance to stress corrosion cracking, pitting, and crevice corrosion.
Product Specifications
| Parameter | Details |
|---|---|
| Standard | ASTM A790, A789, ASME SA790, EN 10216-5, EN 10217-7 |
| Grade | 2205 (UNS S31803, UNS S32205) |
| Size (OD) | 6.0 mm – 610 mm (1/8" – 24") |
| Wall Thickness | 0.5 mm – 25.0 mm |
| Length | 3000 mm, 6000 mm, random lengths (custom cut available) |
| Process | Seamless (cold drawn / cold rolled) or Welded (ERW / EFW) |
| Surface Finish | Mill finish, Pickled, Annealed, Polished |
Chemical Composition (Reference %)
| Element | UNS S31803 | UNS S32205 |
|---|---|---|
| Carbon (C) | ≤ 0.030 | ≤ 0.030 |
| Silicon (Si) | ≤ 1.00 | ≤ 1.00 |
| Manganese (Mn) | ≤ 2.00 | ≤ 2.00 |
| Phosphorus (P) | ≤ 0.030 | ≤ 0.030 |
| Sulfur (S) | ≤ 0.020 | ≤ 0.020 |
| Chromium (Cr) | 21.0 – 23.0 | 22.0 – 23.0 |
| Nickel (Ni) | 4.5 – 6.5 | 4.5 – 6.5 |
| Molybdenum (Mo) | 2.5 – 3.5 | 3.0 – 3.5 |
| Nitrogen (N) | 0.08 – 0.20 | 0.14 – 0.20 |
| Iron (Fe) | Balance | Balance |
UNS S32205 has tighter compositional limits than UNS S31803, providing improved corrosion resistance and consistency.
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥ 620 MPa (≥ 90 ksi) |
| Yield Strength (0.2% offset) | ≥ 450 MPa (≥ 65 ksi) |
| Elongation | ≥ 25% |
| Hardness (Brinell) | ≤ 290 HB |
| Hardness (Rockwell C) | ≤ 30 HRC |
| Impact Strength (Charpy V-notch) | ≥ 100 J at -40°C |
Note: The values above are for reference only. Please refer to the mill test certificate for actual data.
Physical Properties
| Property | Value |
|---|---|
| Density | 7.8 g/cm³ |
| Modulus of Elasticity | 200 GPa (29,000 ksi) |
| Thermal Conductivity (100°C) | 19 W/m·K |
| Specific Heat (0-100°C) | 500 J/kg·K |
| Electrical Resistivity | 850 μΩ·m |
| Magnetic Permeability | Magnetic (ferritic phase) |
Key Features
- High Strength – Approximately twice the yield strength of 304/316 stainless steel
- Excellent Pitting Resistance – PREN (Pitting Resistance Equivalent Number) of 33-35
- Stress Corrosion Cracking Resistance – Superior resistance to chloride SCC
- Good Weldability – Can be welded using standard methods with proper filler metals
- High Thermal Conductivity – Better heat transfer than austenitic grades
- Low Thermal Expansion – Similar to carbon steel, reducing thermal stress issues
- Cost Effective – Allows for wall thickness reduction of 30-50% compared to austenitic grades
Fabrication Guidelines
| Process | Recommendation |
|---|---|
| Welding | Use matching filler metal (2209). Control heat input (0.5-2.5 kJ/mm). Avoid overheating. |
| Bending | Minimum bend radius of 3x OD for cold bending. Use mandrel for tight radii. |
| Cutting | Use abrasive saw or cold saw. Avoid thermal cutting to prevent intergranular corrosion. |
| Machining | Use rigid tooling and positive rake angles. Lower speeds and higher feeds than austenitic. |
| Heat Treatment | Solution anneal at 1040-1100°C followed by water quenching. |
